Children's Educational Microscope

The DinoxScope brings genuine optical performance to early science education. Designed for primary schools, kindergartens, and early childhood settings, it combines real glass achromatic optics with a child-friendly form factor - safe, portable, and built to spark curiosity from the first look.

Full Glass Achromatic Optics

Full glass achromatic objectives deliver sharp, true-colour imaging - free from the blur and chromatic aberration common in plastic-lens alternatives.

Key Features

Adjustable LED Illumination Brightness-controlled LED with turntable diaphragm for optimised, eye-safe lighting in any environment.

Battery Powered Runs on 2x AA batteries - fully portable, no mains connection required.

Ergonomic Design 45-degree inclined viewing head, child-sized focus knobs, and adjustable LED brightness reduce strain during extended use.

Ergonomic Design 45-degree inclined viewing head, child-sized focus knobs, and adjustable LED brightness reduce strain during extended use.

Optional Mobile Phone Holder Attach a smartphone to the eyepiece to capture, record, and share specimens - ideal for group learning.

Everything Included 5 prepared slides, 5 blank glass slides, 20 cover glasses, and specimen preparation tools included in the box.

Technical Specifications


          🔬 🦠 🧫 🧪 🔭
          DinoxScope Specifications

        👁️Viewing Head
        Monocular, 45° inclined

        🔍Eyepiece
        WF10x

        🔄Nosepiece
        Revolving triple nosepiece

        🎯Objectives
        Achromatic DIN 4x / 0.10; Achromatic DIN 10x / 0.25; Achromatic DIN 40x / 0.65, spring loaded

        🧲Stage
        Plain stage with clips, 90 × 90 mm

        🎛️Focusing
        Coaxial coarse knobs, designed for smaller hands

        💡Condenser
        Adjustable disc diaphragm

        ✨Illumination
        LED with adjustable brightness; non-dazzling, eye-safe

        🔋Power
        2 × AA battery

        📐Dimensions
        24 × 20 × 12 cm

        🎁Included Accessories
        5 prepared slides, 5 blank glass slides, 20 cover glasses, specimen preparation tools, mobile phone holder
